The Mars Series IP65 Waterproof LED Downlight delivers high performance with an efficiency of 100–110 lm/W, making it ideal for bathrooms, canopies, retail spaces, and other humid environments. Available in 12–55W, beam angles from 15° to 60°, and CCT options from 2700–5000K, it offers versatile solutions for both commercial and project lighting. With high CRI options (80/90/97Ra) and a precision reflector optic, it provides clean, focused, and comfortable illumination. A reliable and professional IP65 waterproof downlight for any demanding application.
The Mars Series IP65 Waterproof LED Downlight is a high-performance lighting solution designed for professional commercial spaces and project applications. Covering a full power range from 12W to 55W, it offers multiple housing and cutout sizes to fit a wide variety of installation needs. The IP65 ingress protection ensures reliable operation in humid or semi-outdoor environments such as bathrooms, canopies, and industrial areas.
Equipped with a precision reflector optical system, the Mars Series provides four beam angle options—15°, 24°, 38°, and 60°—offering versatility for accent lighting, retail highlighting, and general illumination. With a system efficacy of 100–110 lm/W, the fixture delivers high brightness with significantly reduced energy consumption. Available in 2700K to 5000K CCT options with CRI levels up to 97Ra, it ensures excellent color fidelity, ideal for retail, galleries, hospitality, and other commercial spaces.
The downlight features a robust thermal management design using high-conductivity aluminum, combined with a deep anti-glare reflector structure to provide visual comfort and long-term stability. Whether used in chain stores, hotels, residential bathrooms, indoor showrooms, or semi-outdoor applications, the Mars Series consistently delivers dependable performance and professional-quality illumination.
Features
IP65 waterproof rating for bathrooms, canopies, kitchens, and humid environments.
Comprehensive wattage options (12–55W) for residential, retail, and commercial projects.
High efficiency of 100–110 lm/W reduces energy consumption while maintaining high brightness.
High CRI options (80/90/97Ra) for accurate and vibrant color rendering.
Multiple beam angles (15°–60°) suitable for accent, retail, or general lighting.
Professional reflector optical system for clean, precise light distribution.
Wide CCT range (2700K–5000K) to support various lighting atmospheres.
Low-glare deep reflector design ensures superior visual comfort.
Durable aluminum heat dissipation structure for long-lasting performance.
Multiple cutout sizes compatible with different ceiling systems.
Specification Table
Model
PS-DL12WC49
PS-DL15/20WC49
PS-DL25/30WC49
PS-DL30/35WC49
PS-DL35/40WC49
PS-DL40/45WC49
PS-DL50/55WC49
Power
12W
15/20W
25/30W
30/35W
35/40W
40/45
50/55
Product size(mm)
Φ85*65mm
Φ108*76mm
Φ140*89mm
Φ140*89mm
Φ160*99mm
Φ180*109mm
Φ220*126mm
Input Voltage
AC220-240V 50/60Hz
LED Type
Bridgelux/Citizen/Cree COB
Power Supply
Tridonic / Osram / Philips / Boke
Efficacy(lm/W)
100-110LM/W
Lumen Output±5%
1200LM
1500/2000LM
2500/3000LM
3000/3500LM
3500/4000LM
4000/4500LM
5000/5500LM
Beam Angle
60/90°
CCT (K)
2700/3000K/3500K/4000K/5000K
CRI
Ra80/Ra90/Ra97
PF
>0.9
SDCM
<3
UGR
<19
Material
Die-Casting Aluminum
THD
<15
IP Rate
IP65
Dimming
Non-dimming (Default) /1-10V / Dali/BLE dimming
Certificate
CE/RoHS/CB/TUV/SAA/C-Tick
Warranty
5 Years
Q’TY(PCS)/carton
24pcs
18pcs
12pcs
12pcs
8pcs
8pcs
8pcs
N.W.(KG/carton)
14.9kg
15.2kg
13.6kg
17.2kg
14.4kg
15.6kg
17.8kg
Carton Size(mm)
540*430*340mm
460*460*360mm
560*410*400mm
610*450*430mm
500*500*430mm
500*500*430mm
500*500*430mm
G.W.(KG/carton)
16.9kg
17.2kg
15.6kg
19.2kg
16.4kg
16.6kg
17.9kg
Applications
The Mars Series IP65 Waterproof Downlight is engineered for environments that demand both high lighting performance and strong durability. Its IP65 protection rating makes it ideal for bathrooms, shower areas, kitchens, outdoor canopies, and other humid locations, ensuring consistent operation even under challenging conditions. With high-CRI options and precision reflector optics, it delivers clean, focused illumination—perfect for retail stores, fashion boutiques, and display areas, where accurate color rendering and clear accent lighting are essential.
In hospitality and commercial complexes, the wide wattage and beam angle options allow the Mars Series to adapt seamlessly to lobbies, corridors, meeting rooms, guest rooms, and more. Whether used for general lighting or accent lighting, it provides uniform brightness, visual comfort, and refined ambiance. The strong thermal design and stable structure also make it suitable for long-hour operation in offices, supermarkets, and chain commercial spaces.
From indoor environments to semi-outdoor applications, the Mars Series delivers a reliable, energy-efficient, and visually comfortable lighting solution that enhances the atmosphere and functionality of any space.
Documents
2025.12.01
0.00KB
Faqs
Q.Are your products backed by a guarantee?
A.Yes. Our items have a warranty of 3-5 years.
Q.Is it possible to have my company's logo printed on an LED light product?
A.Yes. Please contact us in writing before we begin production so that we can validate the design using our sample first.
