Certificate:
Power
CRI (Ra)
IP Rating
Beam Angle
Voltage
Engineered for long-term operation, this energy saving track linear light helps businesses lower electricity bills, reduce carbon footprint, and comply with modern energy regulations, while maintaining professional lighting quality and visual comfort.
Compared with conventional track lighting, 160 lm/W track linear light achieves the same or higher brightness with lower wattage, making it an ideal choice for projects focused on energy efficiency, cost reduction, and sustainability.
| Model | PS-TL35/40/50/60/70WL64PLUS |
| Power | 35/40/50/60/70W |
| Product size(mm) | L1148*W63.6*H41.5mm |
| Input Voltage | AC220-240V 50/60Hz |
| LED Type | SMD 2835 |
| Power Supply | Tridonic / Osram / Philips / Boke |
| Efficacy(lm/W) | 150LM-160LM/W |
| Lumen Output±5% | 6400LM-9000LM |
| Beam Angle | 30°/60°/90°/ 120°/LR25/LR30/P20 |
| CCT (K) | 2700 / 3000K / 4000K / 5000/6000 K |
| CRI | Ra83 / Ra92 |
| PF | >0.9 |
| SDCM | <3 |
| UGR | <19 |
| Track Adapt | 2/3/4/6wire |
| Material | Die-Casting Aluminum |
| THD | <15 |
| IP Rate | IP20 |
| Dimming | Non-dimming (Default) /1-10V / Dali/BLE dimming |
| Certificate | CE/RoHS/CB/TUV/SAA/C-Tick |
| Warranty | 5 Years |
| Q’TY(PCS)/carton | 4pcs |
| N.W.(KG/carton) | 20kg |
| Carton Size(mm) | 1235*305*305mm |
| G.W.(KG/carton) | 22kg |
A.Yes. We provide a 3-5 year warranty on all of our goods.
A.Yes. Before we begin production, kindly inform us in writing and validate the design using our sample.
