Anti Glare Led Track Panel Light for Retail & Office Lighting Ugr＜19
Product Code: PS-TL35/40/50/60W-P125G
Certificate:
35/40/50/60W
Power
83/92Ra
CRI
120lm/w
Lumen Efficiency
SMD 2835/3030
LED Chip
Philips/Osram / Tridonic/BOKE
LED Driver
Specification Table
| Model | PS-TPL30/40/50/60W-P125G |
| Power | 30/40/50/60W |
| Product size(mm) | 93mm*125mm*575mm |
| Input Voltage | AC220-240V 50/60Hz |
| LED Type | Lumileds/Osram SMD 2835/3030 |
| Power Supply | Philips/Osran/Tridonic/BOKE/Eaglerise |
| Efficacy(lm/W) | 150LM/W |
| Beam Angle | 60°/80° |
| CCT (K) | 2700/3000K/3500K/4000K/5000K |
| CRI | Ra83/Ra92 |
| PF | >0.9 |
| SDCM | <3 |
| UGR | <15 |
| Track Adapt | 2/3/4/6wire |
| Material | Die-Casting Aluminum |
| THD | <15 |
| IP Rate | IP20 |
| Input Voltage Shock | <380VAC |
| Start/Switchover/Turn off | <0.5s(AC start),<0.5s(DCstart),<0.3s(AC/DC switchover),<0.5s(Turn off) |
| Switching Cycles | >100,000 switching cycles |
| Withstand VoItage | 1/P-0/P:3750VAC |
| Mainssurge Capability | L-N:2KV(90%/270°, 5 times each with an interval of 60s) |
| Life-time | Nominal life-time up to 100,000H |
| Operating Temperature | -20~50°C |
| Operating Humidity | 5-85% RH, non-condensing |
| Storage Temp./Humidity | -40~80°C, 5-85% RH, non-condensing |
| Dimming | Non-dimming (Default) /1-10V / Dali/BLE dimming |
| Certificate | CE/RoHS/CB/TUV/SAA/C-Tick |
| Warranty | 5 Years |
| QTY / CTN Size | 9 PCS / 635*314*324 MM |
| N.W. / G.W. | 15 KG / 16 KG |
Applications
- Retail Store Lighting
Provides wide and uniform illumination for shelves and shopping areas while reducing glare for customers.
- Office Lighting
UGR<19 optical performance improves visual comfort and helps reduce eye fatigue during long working hours.
- Supermarket Lighting
Creates bright and balanced aisle lighting with high efficiency and excellent coverage.
- Showroom & Exhibition Lighting
High CRI performance enhances product appearance and creates premium display environments.
FAQ
-
Q.What is the benefit of UGR<19 for this LED Track Panel Light?
A.UGR<19 helps reduce direct glare and reflected light, creating a more comfortable environment for offices and commercial spaces.
-
Q.Can this LED Track Panel Light replace traditional panel lights?
A.Yes. It provides uniform area lighting while offering flexible track installation and easier layout adjustment.
-
Q.What power options are available?
A.The Aden Series supports 35W, 40W, 50W, and 60W power options for different project requirements.
-
Q.Does this product support smart lighting control?
A.Yes. It supports DALI, 0-10V, and Triac dimming systems for intelligent lighting management.
-
Q.What track systems can be used with this product?
A.It is compatible with both 1-phase and 3-phase track systems.
-
Q.Can I customize the reflector color and CCT?
A.Yes. Different reflector finishes and 2700K-5000K color temperatures are available for various design requirements.
