12-30W 160 Lm/W Adjustable Gimbal Led Downlight
Product Code: PS-GDL12/15/20/25/30-C38H
Certificate:
Add To Quote
12-50W
Power
80/90/97Ra
CRI
160 lm/W
Lumen Efficiency
COB
LED Chip
CE Flicker Free driver
LED Driver
Specification Table
| Model | PS-GDL12W-C38H | PS-GDL15W-C38H | PS-GDL20W-C38H | PS-GDL25W-C38H | PS-GDL30W-C38H |
| Power | 12W | 15W | 20W | 25W | 30W |
| Product size(mm) | Φ90*60 | Φ102*80 | Φ125*108 | Φ140*115 | Φ160*135 |
| Cut-out | 75mm | 95mm | 110mm | 125mm | 145mm |
| Input Voltage | AC 220-240V 50/60Hz | ||||
| LED Type | Citizen/Luminus/Cree COB | ||||
| Power Supply | Tridonic / Osram / Philips / Boke | ||||
| Efficacy(lm/W) | 160 LM/W | ||||
| Beam Angle | 15° / 24° / 38° | ||||
| CCT (K) | 2700K / 3000K / 3500K / 4000K / 5000K | ||||
| CRI | Ra80/Ra90/Ra97 | ||||
| PF | >0.9 | ||||
| SDCM | <3 | ||||
| UGR | <19 | ||||
| Material | Die-Casting Aluminum | ||||
| THD | <15 | ||||
| IP Rate | IP20 | ||||
| Input Voltage Shock | <380V AC | ||||
| Start/Switchover/Turn off | <0.5s(AC start),<0.5s(DCstart),<0.3s(AC/DC switchover),<0.5s(Turn off) | ||||
| Switching Cycles | >100,000 switching cycles | ||||
| Withstand VoItage | 1/P-0/P:3750VAC | ||||
| Mainssurge Capability | L-N:2KV(90%/270°, 5 times each with an interval of 60s) | ||||
| Life-time | Nominal life-time up to 100,000H | ||||
| Operating Temperature | -20~50°C | ||||
| Operating Humidity | 5-85% RH, non-condensing | ||||
| Storage Temp./Humidity | -40~80°C, 5-85% RH, non-condensing | ||||
| Dimming | Non-dimming (Default) /1-10V / Dali/BLE dimming | ||||
| Certificate | CE/RoHS/CB/TUV/SAA/C-Tick | ||||
| Warranty | 5 Years | ||||
| Q’TY(PCS)/carton | 30pcs | 30pcs | 24pcs | 18pcs | 12pcs |
| Carton Size(mm) | 400*200*435mm | 420*210*460mm | 520*225*400mm | 430*300*505mm | 540*365*400mm |
| N.W.(KG/carton) | 14kg | 15kg | 15.8kg | 17.8kg | 19kg |
| G.W.(KG/carton) | 16Kg | 17kg | 17.8kg | 19.8kg | 21kg |
Applications
The 160 lm/W adjustable gimbal LED downlight is ideal for commercial spaces that require both high energy efficiency and flexible lighting direction. Its adjustable gimbal design allows the beam to be aimed precisely at products, displays, walls, or key architectural features, while the high luminous efficacy helps reduce overall power consumption.
- High-End Retail and Boutiques
In the world of retail, lighting drives sales. Our Gimbal LED Downlight features a high CRI of 97Ra. This ensures that clothing, jewelry, and luxury goods look their best. The adjustable head allows you to highlight new arrivals. You can focus the beam on specific displays or mannequins. It creates a dynamic shopping experience that captures customer attention.
- Museums and Art Galleries
Artworks require precise and gentle illumination. The Sofia Series offers various beam angles like 15° and 24°. These narrow beams are perfect for spotlighting paintings and sculptures. The gimbal mechanism allows for fine-tuning without moving the entire fixture. It protects sensitive art while providing the perfect visual contrast.
- Hotels and Hospitality
First impressions matter in hotel lobbies and corridors. Use these gimbal lights to wash walls with warm, inviting light. They can also highlight decorative features or signage. The sleek, recessed design blends perfectly with modern architecture. It provides a clean look while offering powerful lighting functionalitity.
- Automobile Showrooms
Car showrooms need bright and high-impact lighting. Our 40W and 50W models provide the necessary intensity for large spaces. The Gimbal LED Downlight can be angled to reduce glare on metallic surfaces. It makes cars look sleek and vibrant under the spotlight.
- Premium Residential Projects
This series is also ideal for modern homes. Use it in living rooms to highlight feature walls or bookshelves. In kitchens, it provides excellent task lighting over islands. Its versatility ensures that your home lighting remains functional and stylish for years to come.
Faqs
-
Q.What is the luminous efficacy of this gimbal LED downlight?
A.It delivers a luminous efficacy of up to 160 lm/W, providing high lumen output with lower energy consumption for commercial lighting projects.
-
Q.Can the lighting direction be adjusted?
A.Yes. The gimbal design allows the light direction to be adjusted easily, making it suitable for highlighting products, displays, walls, and specific areas within a commercial space.
-
Q.What are the main benefits of 160 lm/W high efficiency?
A.The high luminous efficacy helps deliver more light with less power, reducing overall energy consumption and operating costs while maintaining sufficient brightness for commercial applications.
-
Q.Are different beam angles available?
A.Yes. Multiple beam angle options are available to meet different lighting requirements, from focused accent lighting to wider general illumination.
-
Q.What beam angles are available?
A.The SOFIA Series offers 15°, 24°, and 38° beam angles to meet different accent and general lighting requirements.
-
Q.Are different wattages and color temperatures available?
A.Yes. Different wattages, color temperatures, beam angles, CRI options, and dimming solutions can be provided according to specific project requirements.
-
Q.What is the expected lifetime?
A.The fixture is rated for more than 70,000 hours of operation and is backed by a 5-year warranty.
