Description
The TRENDY Series LED Landscape Street Light is a high-performance outdoor lighting solution designed for modern urban and landscape applications. Featuring Lumileds 3030 LED chips, high-efficiency drivers, and optimized thermal design, it achieves up to 150 lm/W system efficiency with stable performance. Available in 30W to 100W options, this LED street light provides flexible lighting solutions for roads, parks, residential communities, commercial plazas, and public areas.
Key Features
High Efficiency LED Performance: Delivers up to 150 lm/W efficiency to reduce energy consumption and operating costs.Premium LED Components: Uses Lumileds 3030 chips and reliable drivers for stable illumination and long service life.Durable Outdoor Protection: IP65 waterproof, IK08 impact resistant, and 10KV surge protection ensure reliable operation.Flexible Lighting Distribution: Offers 90°, 120°, and 75°×160° beam angles for different road and landscape layouts.Smart Lighting Control: Compatible with 1-10V and DALI dimming systems for smart city lighting applications.Easy Installation and Adjustment: Supports multiple mounting options with adjustable brackets for accurate light positioning.
Specification Table
Model VKS-FL0030-G10 VKS-FL0050-G10 VKS-FL0060-G10 VKS-FL00100-G10
Power 30W
50W
60W
100W
Input Voltage AC220-240V 50/60Hz
LED Type SMD3030
Power Supply Inventronics/Meanwell/Sosen
Efficacy (lm/W) 140-150lm/W
Beam Angle 90° / 120° / 75°X160°
CCT(K) 3000K / 4000K / 5700K
CRI Ra 80/90/95
PF >0.9
SDCM <3
Material Die-casting Aluminum
THD <15
IP Rate IP 65
Dimming Non-dimming (Default)/1-10V/DALI
Certificate CE/RoHS/CB/TUV/SAA/C-Tick
Warranty 5 years
N.W.(KG/Carton) 8.5
8.5
8.5
8.5
Applications
Residential Community Lighting
Provides comfortable lighting for community roads, gardens, and pedestrian pathways. Creates a safe and welcoming nighttime environment.
Suitable for secondary roads, industrial parks, and public streets. The 75°×160° distribution improves road coverage and reduces pole quantity.
Commercial Plaza Lighting
Ideal for shopping centers, outdoor squares, and business areas. Provides bright and uniform illumination for customer activities.
Park & Landscape Lighting
Perfect for parks, resorts, gardens, and scenic areas. Warm color temperatures create a comfortable outdoor atmosphere.
Documents
About PS-FL-0030-100W G10 product the title name of this pdf is put in
Faqs
Q.What power options are available for the TRENDY Series LED Landscape Street Light?
A.The series includes 30W, 50W, 60W, and 100W models to meet different outdoor lighting requirements.
Q.Can this LED street light work in harsh weather conditions?
A.Yes. With IP65 protection, IK08 impact resistance, and a working temperature range of -30°C to +50°C, it is suitable for outdoor environments.
Q.Does this street light support smart lighting systems?
A.Yes. It supports 1-10V and DALI dimming control for smart city and energy-saving lighting systems.
Q.How do I choose the suitable beam angle?
A.90° is suitable for focused areas, 120° works well for open spaces, and 75°×160° is recommended for roads requiring wider coverage.
Q.What is the lifespan of this LED landscape street light?
A.The lifespan is over 60,000 hours (L70), helping reduce maintenance frequency and replacement costs.
Q.Can the mounting angle be adjusted after installation?
A.Yes. The adjustable mounting design allows installers to optimize the lighting direction according to project requirements.
