| Model | PS-TL5/7WGU10 |
| Power | 5/7 W |
| Product Size(mm) | D55*H95 mm |
| Input Voltage | AC220-240V 50/60Hz |
| LED Type | COB |
| Power Supply | Tridonic/Osram/Philips/BOKE |
| Efficacy (lm/W) | 50-60 lm/W |
| Lumen Output ±5% | 400-560 LM |
| Beam Angle | 10°/24°/38° |
| CCT(K) | 2700/3000/4000/5700 K |
| CRI | Ra80/90/95 |
| PF | >0.9 |
| SDCM | <3 |
| UGR | <15 |
| Track Adaptor | 2/3/4 wires |
| Material | Die-casting Aluminum |
| THD | <15 |
| IP Rate | IP 20 |
| Input Voltage Shock | <380V AC |
| Start/Switchover/Turn off | <0.5s(AC start),<0.5s(DCstart),<0.3s(AC/DC switchover),<0.5s(Turn off) |
| Switching Cycles | >100,000 switching cycles |
| Withstand VoItage | 1/P-0/P: 3750V AC |
| Mainssurge Capability | L-N:2KV(90%/270°, 5 times each with an interval of 60s) |
| Life-time | Nominal life-time up to 100,000H |
| Operating Temperature | -20~50°C |
| Operating Humidity | 5-85% RH, non-condensing |
| Storage Temp./Humidity | -40~80°C, 5-85% RH, non-condensing |
| Dimming | Non-dimming (Default)/1-10V/Dali/BLE |
| Certificate | CE/RoHS/CB/TUV/SAA/C-Tick |
| Warranty | 3 years |
| QTY / CTN Size | 8 pcs / 450*320*450 mm |
| N.W. / G.W. | 11.2 / 13.2 kg |
The LED GU10 track light is ideal for retail stores, boutiques, galleries, showrooms, cafés, restaurants, hotels, and residential interiors. Its adjustable beam direction makes it perfect for highlighting products, artwork, shelves, and decorative features while creating a comfortable lighting atmosphere
A.It is compatible with standard GU10 LED bulbs widely available on the market.
A.The bulb can be included or supplied separately according to project requirements.
A.Yes. Simply replace the GU10 bulb with the required color temperature.
A.Yes. Different GU10 bulbs provide narrow, medium, or wide beam angles.
A.Yes. The head supports 320° horizontal rotation and 90° vertical tilt.
A.It supports standard 2-wire, 3-wire, and 4-wire track systems.
A.It suits shops, cafés, restaurants, offices.
A.Yes. Only the GU10 bulb needs replacement, reducing maintenance time and cost.
A.A 3-year warranty is available
