The White LED Track Light supports DMX512 control for smooth dimming, RGBW adjustment, grouping, and scene management. Its 6-wire adaptor fits standard track systems, while 100–110 lm/W efficiency ensures bright, uniform illumination. Ideal for shops, restaurants, ballrooms, stages, and exhibition spaces.
Features
DMX512 Control: Supports professional dimming, grouping, colour adjustment, and scene control.
Smooth 0–100% Dimming: Provides accurate and flicker-free brightness adjustment.
RGBW Colour Options: Creates white light and multiple dynamic colour effects.
6-Wire Track Compatibility: Compatible with standard 6-wire track rail systems.
100–110 lm/W Efficiency: Delivers high lumen output with reduced energy consumption.
Uniform Light Distribution: Produces bright, clean, and even illumination.
L-N:2KV(90%/270°, 5 times each with an interval of 60s)
Life-time
Nominal life-time up to 100,000H
Operating Temperature
-20~50°C
Operating Humidity
5-85% RH, non-condensing
Storage Temp./Humidity
-40~80°C, 5-85% RH, non-condensing
THD
<15
IP Rate
IP20
Dimming
DMX512 dimming
Certificate
CE/RoHS/CB/TUV/SAA/C-Tick
Warranty
5 Years
QTY/CTN Size
12 pcs / 420*320*310 mm
NW / GW
12.5 / 14 kg
Applications
The 30W Dimmable White Track Light is ideal for retail stores, galleries, museums, showrooms, restaurants, and hotels. Its adjustable design provides precise accent lighting for products, artworks, displays, and architectural details.
Smooth dimming allows the brightness to be adapted for different spaces, activities, and lighting scenes.
Documents
2022.03.05
0.00KB
Faqs
Q.What is the power of this track light?
A.The track light has a 30W power output.
Q.Is the track light dimmable?
A.Yes. It supports smooth brightness adjustment from 0% to 100%.
Q.Does it support DMX512 control?
A.Yes. DMX512 control is available for professional lighting projects.
Q.Can multiple track lights be controlled together?
A.Yes. Fixtures can be grouped for synchronized dimming and scene control.
Q.Can each fixture be controlled independently?
A.Yes. Individual addressing is available through a compatible DMX512 system.
Q.What is the luminous efficacy?
A.The fixture provides approximately 100–110 lm/W.
Q.What track system does it use?
A.It is available with a 6-wire adaptor for compatible track rail systems.
Q.Is installation complicated?
A.No. The track-mounted design allows quick installation and repositioning.
