Double Adjustable Track Grille Linear Light With 40-50W for Retail Display
Product Code: PS-TL40/45/50W-DGL45
Certificate:
40/45/50W
Power
83Ra/92Ra
CRI (Ra)
IP20
IP Rating
30°/50°/80°/ 30x70°
Beam Angle
220~240v
Voltage
Specification Table
| Model | PS-TL40/45/50W-DGL45 |
| Power | 40/45/50W |
| Product size(mm) | L566*W145*H49mm |
| Input Voltage | AC220-240V 50/60Hz |
| LED Type | Lumileds/Osram SMD 2835/3030 |
| Power Supply | Osram / Tridonic /Global / KGP / Powergear |
| Efficacy(lm/W) | 100LM-120LM/W |
| Beam Angle | 30°/50°/80°/ 30×70° |
| CCT (K) | 2700 / 3000K / 3500K / 4000K / 5000K |
| CRI | Ra83 / Ra92 |
| PF | >0.9 |
| SDCM | <3 |
| UGR | <19 |
| Track Adapt | 2/3/4/6wire |
| Material | Die-Casting Aluminum |
| THD | <15 |
| IP Rate | IP20 |
| Input Voltage Shock | <380VAC |
| Start/Switchover/Turn off | <0.5s(AC start),<0.5s(DCstart),<0.3s(AC/DC switchover),<0.5s(Turn off) |
| Switching Cycles | >100,000 switching cycles |
| Withstand VoItage | 1/P-0/P:3750VAC |
| Mainssurge Capability | L-N:2KV(90%/270°, 5 times each with an interval of 60s) |
| Life-time | Nominal life-time up to 100,000H |
| Operating Temperature | -20~50°C |
| Operating Humidity | 5-85% RH, non-condensing |
| Storage Temp./Humidity | -40~80°C, 5-85% RH, non-condensing |
| Dimming | Non-dimming (Default) /1-10V / Dali/BLE dimming |
| Certificate | CE/RoHS/CB/TUV/SAA/C-Tick |
| Warranty | 5 Years |
| QTY / CTN Size | 3 PCS / 635*365*345 MM |
| N.W. / G.W. | 15 KG / 17 KG |
Applications
- Supermarkets: Illuminate both sides of retail shelves while the center diffuser provides comfortable ambient lighting.
- Fashion Retail Stores: Highlight clothing displays from different angles to create an attractive shopping experience.
- Museums & Art Galleries: Provide glare-free directional lighting for artworks while maintaining a refined architectural look.
- Commercial Showrooms: Adjust each lighting module independently to emphasize featured products and display zones.
Faqs
-
Q.Why is the dual adjustable design beneficial?
A.Each side of the fixture can be adjusted independently, allowing one luminaire to illuminate two different display areas simultaneously, reducing fixture quantity and improving lighting flexibility.
-
Q.Can the center PC cover be used as a light source?
A.Yes. The center PC diffuser can provide soft ambient illumination or function as a decorative architectural element, depending on the project design.
-
Q.Is this fixture suitable for supermarket shelf lighting?
A.Yes. The optional 30×70° asymmetric beam angle is specifically designed for shelf and aisle lighting, providing excellent vertical illumination.
-
Q.Does it support smart lighting control systems?
A.Yes. It supports On-Off, 0-10V, Triac and DALI dimming, making it compatible with most commercial lighting control systems.
-
Q.Can both adjustable grille modules be rotated independently?
A.Yes. The left and right grille modules can each be adjusted to different angles, allowing flexible lighting for multiple display directions.
-
Q.What track systems is it compatible with?
A.It is available with both 1-phase and 3-phase track adapters, making it compatible with most standard commercial track systems.
-
Q.Is the fixture difficult to maintain?
A.No. The high-quality aluminum housing and premium LED components provide excellent heat dissipation and long service life, minimizing maintenance requirements.
-
Q.What applications is this product best suited for?
A.It is ideal for supermarkets, retail stores, fashion boutiques, galleries, museums, showrooms and other commercial spaces requiring flexible, anti-glare lighting.
